WATTS 0123476
LF 1/2SWT FBVS-3C-CC W/CAP
SKU
580913
WATTS®, 0123476, Ball Valve, 2-Piece, Series: LFFBV-3, 1/2 x 3/4 in Nominal, Threaded x Hose End Style, 400 psi Pressure, -40 to 400 deg F, Full Port, Media: Water, Chrome Plated Brass Ball, 2-9/16 in Inlet to Outlet Length, 2-9/16 in Top to Inlet Center, Virgin PTFE/Fluorocarbon Elastomer Softgoods, Import
- Machined chrome plated lead-free brass ball
- Cap and chain
- Fluorocarbon elastomer stem O-Ring prevents stem leaks
- Adjustable stem packing gland nut
- Virgin PTFE packing, thrust washer and seat
- The wetted surface of this product contacted by consumable water contains less than 0.25% of lead by weight
- You are required to thoroughly read all installation instructions and product safety information before beginning the installation of this product
- Virgin PTFE stem packing seal and fluorocarbon elastomer O-ring
| Softgoods Material | Virgin PTFE/Fluorocarbon Elastomer |
|---|---|
| Port Type | Full |
| End Style | Threaded x Hose |
| Media | Water |
| Ball Material | Chrome Plated Brass |
| Domestic/Import | Import |
| Inlet to Outlet Length | 2-9/16 in |
| Top to Inlet Center | 2-9/16 in |
| Type | 2-Piece |
| Pressure Rating | 400 psi |
| Body Material | Forged Brass |
| Nominal Size | 1/2 x 3/4 in |
| Temperature Rating | -40 to 400 deg F |
| Series | LFFBV-3 |
| Trim Material | Brass Stem |
| Brand | Watts |
| Use | Sweat |
| Type | Ball Valve |
| Size | 1/2" |
