WATTS 0525687
LF 10"LUG BFV GEAR-OP AL/BRZ
SKU
369431
WATTS®, 0525687, Butterfly Valve, Full Lug Style, Series: BF03-121, 10 in Nominal, Flanged End Style, 125/150 lb Pressure Class, 5 to 248 deg F, Media: Gas/Liquid/Slurry, Gear Actuator, Ductile Iron Body, Aluminum Bronze Disc, 416 Stainless Steel (Stem)/Stainless Steel (Taper Pin) Stem & Pin, Buna-N Softgoods, 21-1/4 in H Dimensions, Import
- EPDM seat
- 416 stainless steel shaft
- The wetted surface of this product contacted by consumable water contains less than 0.25% of lead by weight
- Buna-N O-ring stem
| Softgoods Material | Buna-N |
|---|---|
| Dimensions | 21-1/4 in H |
| End Style | Flanged |
| Stem & Pin Material | 416 Stainless Steel (Stem)/Stainless Steel (Taper Pin) |
| Disc Material | Aluminum Bronze |
| Media | Gas/Liquid/Slurry |
| Pressure Class | 125/150 lb |
| Domestic/Import | Import |
| Type | Full Lug Style |
| Body Material | Ductile Iron |
| Nominal Size | 10 in |
| Temperature Rating | 5 to 248 deg F |
| Series | BF-03-121-1G-M2 |
| Actuator Type | Gear |
| Brand | Watts |
| Type | Butterfly Valves |
