Jomar Valve 104-526PG
11/4" F1960 LF BALL VALVE
SKU
914746
Jomar Valve® Ball Valve, 2-Piece, 1-1/4 in Nominal, PEX Expansion End Style, 400 psi WOG Pressure, 200 deg F, Standard Port, Stainless Steel Ball, 4.65 in Inlet to Outlet Length, 2-1/2 in Top to Inlet Center, Brass Body, 304 Stainless Steel Stem and PTFE Seat Trim, PTFE/Buna-N Softgoods
- Gland follower and single O-Ring stem design
- Blow-out proof stem
- 100% leak tested
- Wetted surfaces contains less than 0.25 % lead content
- Expansion connection rated to 150 psi WOG up to 200 deg F
- PTFE packing and Buna-N O-ring
| Softgoods Material | PTFE/Buna-N |
|---|---|
| Port Type | Standard |
| End Style | PEX Expansion |
| Ball Material | Stainless Steel |
| Inlet to Outlet Length | 4.65 in |
| Top to Inlet Center | 2-1/2 in |
| Type | 2-Piece |
| Pressure Rating | 400 psi WOG |
| Body Material | Brass |
| Nominal Size | 1-1/4 in |
| Temperature Rating | 200 deg F |
| Trim Material | 304 Stainless Steel Stem and PTFE Seat |
| Brand | Jomar |
