EATON 1242-7B-BOX
15A HEAVY DUTY 4-WAY SW B
SKU
676453
EATON Arrow Hart® Toggle Switch, 4-Way Grounding, Series: 1242-7, 120 VAC, 15 A, 1/2 to 2 hp Power, Toggle Actuator, Wall Mounting, Screw Terminal, 30000 Cycles Operating Cycles, Polycarbonate, Brown, Environmental Conditions: -20 to 60 deg C Temperature, 1.31 in W x 1.05 in D Dimensions
- 3-way switches feature additional push-in common termination for feed through tapping
- Push-in terminals accept 14 AWG solid wire only
- Side wire terminals accept up to 10 AWG solid wire
- Long, broad mounting strap virtually eliminates floating installations
- Patented built-in wire stripper for 14 and 12 AWG wire to speed installation
- Patented built-in wire looper for pre-looping
- Tri-combo screws accept slotted, Phillips® and Robertson head tools for installation flexibility
- Lighted toggle glows in OFF position
- 3.28 in L screw to screw
- 2.4 in L back
| Dimensions | 1.31 in W x 1.05 in D |
|---|---|
| Power Rating | 1/2 to 2 hp |
| Voltage Rating | 120 VAC |
| Operating Cycles | 30000 Cycles |
| Series | 1242-7 |
| Mounting | Wall |
| Environmental Conditions | -20 to 60 deg C Temperature |
| Color | Brown |
| Type | 4-Way Grounding |
| Material | Polycarbonate |
| Terminal Type | Screw |
| Amperage Rating | 15 A |
| Actuator | Toggle |
| Brand | Eaton |
| Amperage | 15 Amp |
| Voltage | 120V |
| Color | Brown |
