Spears 1722-020
2"PVC SOC END Y-PATTERN VALVE
SKU
895843
Spears® Y-Pattern Valve, 2 in Nominal, Socket End Style, 150 psi Pressure, 140 deg F, Handwheel Actuator, 7-1/2 in Inlet to Outlet Length, 8-1/2 in Top to Inlet Center, PVC Body, PVC Trim, EPDM/FKM O-Ring Softgoods, 3-1/2 in Diameter Hand Wheel, Gray, Domestic
- Chemical and corrosion resistant PVC gray, PVC clear or CPVC construction
- Buttress thread bonnet
- Fully serviceable, replaceable components
- Standard o-ring seal seating disc and seals
- High impact polypropylene handle
- Assembled with silicone free, water soluble lubricant
| Softgoods Material | EPDM/FKM O-Ring |
|---|---|
| End Style | Socket |
| Hand Wheel Diameter | 3-1/2 in |
| Domestic/Import | Domestic |
| Inlet to Outlet Length | 7-1/2 in |
| Top to Inlet Center | 8-1/2 in |
| Pressure Rating | 150 psi |
| Body Material | PVC |
| Nominal Size | 2 in |
| Temperature Rating | 140 deg F |
| Color | Gray |
| Actuator Type | Handwheel |
| Trim Material | PVC |
| Brand | Spears |
| Size | 2" |
