Xylem 1AS15

Goulds Aquavar® Solo2™ Constant Pressure Controller, 230 VAC, 1 ph, 14 to 122 deg F, Domestic

• Simple wiring and menu set-up
• Turns virtually any conventional system into a premium constant pressure system
• Fade-resistant LED display indicates system pressure, speed and current
• Error log displays last four faults and can be reset
• LED display clearly indicates actual system pressure, output frequency, current draw and error log
• Dual system set points for advanced system application
• Programmable output relay can be configured to run optional accessories such as a chlorinator, or link to a home monitoring system
• Rotary switch to set current limit to match motor service factor amps (SFA)
• Choice of low or high sensitivity
• Choose a 5 or 20 psi pressure drop for restarts
• Set on or off depending on application
• Standard pressure sensor cable is 10 ft L
• Integrated output motor filter protects the motor from voltage spikes and limits electrical interference with devices such as portable telephones, radios, televisions and garage door openers
• 9.9 in W x 5.3 in D x 18.6 in H
• Pressure set point adjustable from 20 to 85 psi using the standard 100 psi transducer
• Input voltage single-phase, 230 V, 2-wire grounded system
• Output voltage variable voltage, variable frequency, single phase power to the 2-wire or 3-wire motor
• NEMA 3R enclosure rainproof, outdoor/indoor rated enclosure
• Speed/frequency 30 to 60 Hz only
• Motor Compatibility with 1/2 to 2 hp
