Spears 4529-010
1"PVC TRUE UNION CHECK VALVE
SKU
631309
Spears® Ball Check Valve, True Union 2000 Industrial, 1 in Nominal, Socket/FNPT, 235 psi, 73 deg F, Media: Water, 5-3/16 in Inlet to Outlet Length, PVC Ball, PVC Body, EPDM Softgoods, Gray, 1-7/8 in H, Domestic
- Chemical and corrosion resistant PVC construction
- Strong, buttress thread union nuts
- Spears® Safe-T-Blocked® seal carrier
- Uses standard O-Ring seat
- Fully serviceable, replaceable components
- Suitable for either horizontal or vertical installations and vacuum service
- Assembled with silicone free, water soluble lubricant
- EPDM O-ring
| Ball Material | PVC |
|---|---|
| End Style | Socket/FNPT |
| Softgoods Material | EPDM |
| Temperature Rating | 73 deg F |
| Color | Gray |
| Inlet to Outlet Length | 5-3/16 in |
| Domestic/Import | Domestic |
| Media | Water |
| Dimensions | 1-7/8 in H |
| Pressure Rating | 235 psi |
| Nominal Size | 1 in |
| Type | True Union 2000 Industrial |
| Body Material | PVC |
| Brand | Spears |
