American Standard 606B121.002
A/S SELECT EXP TOILET FV 1.28
SKU
754428
American Standard Flush Valve, Exposed Hands-Free Operated, Selectronic® Collection, Urinal Fixture, Plug-In AC Powered Power Source, 0.125 gpf Flush, 3/4 in NPT Inlet, 3/4 in Spud Coupling, Piston Operated Valve Design, Connection Location: Back Spud, 400 to 800 mm Sensor, 20 psi Flowing/80 psi Static Pressure, Semi-Red Brass Alloy, Rough Brass, Import
- Self-cleaning piston eliminates routine maintenance
- No diaphragms to replace or filter screens to clean
- Integral wiper spring cleans the refill orifice with every flush
- Delivers reliable operation even with poor water quality
- Hygienic, touch-free operation
- Flexible Selectronic® platform with programmable sensor
- Fully mechanical manual override - allows valve to flush during a power failure
- Fail-safe - valve automatically closes on loss of power or water pressure
- Power kit sold separately
- Can be installed left or right hand
- An impressive collection of Selectronic® sensor operated flush valves are designed to meet the demands of high use spaces labor saving installation, water saving operation and time saving maintenance and care
- State-of-the-Art electronics prevent ghost flushing
- Dezincification-resistant semi-red brass alloy
- Adjustable sanitary flush cleans the fixture and maintains the trap seal
- Chemical-resistant EPDM seals for long life
| Material | Semi-Red Brass Alloy |
|---|---|
| Flush Rate | 0.125 gpf |
| Pressure Rating | 20 psi Flowing/80 psi Static |
| Sensor Range | 400 to 800 mm |
| Spud Coupling | 3/4 in |
| Valve Design | Piston Operated |
| Fixture Type | Urinal |
| Connection Location | Back Spud |
| Valve Design | Piston Operated |
| Spud Coupling | 3/4 in |
| Pressure Rating | 20 psi Flowing/80 psi Static |
| Power Source | Plug-In AC Powered |
| Type | Exposed Hands-Free Operated |
| Inlet Size | 3/4 in NPT |
| Finish/Color | Rough Brass |
| Collection | Selectronic® |
| Domestic/Import | Import |
| Brand | American Standard |
