BrassCraft 68-8-6X
LF 1/2 OD X 3/8 COMP MALE ADAPTER
SKU
1173
BrassCraft® Tube Reducing Adapter, Series: 68 Series, Fitting/Connector: Adapter, 1/2 x 3/8 in Nominal, Compression x MNPT End Style, 0.032 in Thickness, 11/16 in Hex, 200 psi Pressure, -65 to 250 deg F, Brass, Rough, 0.46 in ID Dimensions, Import
- Does not require any flaring, soldering or other type of tubing preparation
- Manufactured from low lead compliant brass
- For use with potable water, many different types of instrumentation applications, hydraulic and pneumatic systems
- Designed to be used with aluminum, copper and plastic tubing, not for use with steel tubing
- Plastic tubing requires 63PT insert and 60PT sleeve
| Temperature Rating | -65 to 250 deg F |
|---|---|
| Finish | Rough |
| Dimensions | 0.46 in ID |
| End Style | Compression x MNPT |
| Hex Size | 11/16 in |
| Domestic/Import | Import |
| Nominal Size | 1/2 x 3/8 in |
| Fitting/Connector Type | Adapter |
| Material | Brass |
| Thickness | 0.032 in |
| Series | 68 Series |
| Pressure Rating | 200 psi |
| Brand | BrassCraft |
| OD Tube Size | 3/8" |
| Type | Male Adapters |
