BrassCraft C14X C
LF CP 3/8OD X 5/8OD COMP UNION
SKU
1214
BrassCraft® Tube Reducing Union, Series: 62-DT, Coupling Fitting/Connector, 5/8 x 3/8 in Nominal, Compression End Style, 0.032 to 0.035 in Thickness, 13/16 in Hex, 1-3/4 in Length, 150/200 psi Pressure, -65 to 250 deg F, Brass, Polished Chrome, Domestic
- Do not require any flaring, soldering or other type of tubing preparation
- Available in a broad range of sizes and styles
- Manufactured from low lead compliant brass
- For use with potable water, many different types of instrumentation applications, hydraulic and pneumatic systems
- Plastic tubing requires 63PT insert and 60PT sleeve
| Temperature Rating | -65 to 250 deg F |
|---|---|
| Finish | Polished Chrome |
| Length | 1-3/4 in |
| End Style | Compression |
| Hex Size | 13/16 in |
| Domestic/Import | Domestic |
| Nominal Size | 5/8 x 3/8 in |
| Fitting/Connector Type | Coupling |
| Material | Brass |
| Thickness | 0.032 to 0.035 in |
| Series | 62-DT |
| Pressure Rating | 150/200 psi |
| Brand | BrassCraft |
| OD Tube Size | 5/8" x 3/8" |
| Type | Unions |
