EATON C25DNF325T
3P 25A CONTACTOR 24V COIL
SKU
836839
EATON Definite Purpose Control Contactor, D Frame Non-Reversing, 24 VAC Coil, 25 A Inductive/35 A Resistive Maximum Load Current, 3 Pole, 50/60 Hz Frequency, Double Break Contact, Box Lug/Quick-Connect Terminal, Open Enclosure, 300000 Cycles Operating Cycles, 150 deg F Operating, Surface Mounting, 3.35 in L x 2.4 in W x 3.75 in H Dimensions
- The universal mounting plate eliminates changing hole patterns when replacing competitive devices
- Variety of terminal styles allows product to meet all specific application needs
- Snap-on accessories require no tools for hassle-free installation
- Quick coil changing ability allows for easy maintenance
- Non-position sensitive mounting allows for fast, convenient set up
- Shrouded or fingerproof terminals reduce possibility of electrical shock
- Open with metal mounting plate
- 15 to 50 A frame
| Coil Voltage | 24 VAC |
|---|---|
| Operating Temperature | 150 deg F |
| Mounting Type | Surface |
| Frequency Rating | 50/60 Hz |
| Type | D Frame Non-Reversing |
| Operating Cycles | 300000 Cycles |
| Contact Type | Double Break |
| Dimensions | 3.35 in L x 2.4 in W x 3.75 in H |
| Terminal Type | Box Lug/Quick-Connect |
| Number of Poles | 3 |
| Enclosure Type | Open |
| Maximum Load Current | 25 A Inductive/35 A Resistive |
| Brand | Eaton |
