EATON 277B-BOX
SP SW OVER PILOT LIGHT BR
SKU
676490
EATON Arrow Hart™ Eaton Wiring Devices Combination Toggle Switch, 3-Way Duplex, 120 VAC, 15 A, 1 Pole, Wall Mounting, Screw Terminal, -20 to 60 deg C, Thermoplastic, Brown, 4.19 in H x 1.37 in W x 0.95 in D Dimensions
- Back and Side wire connection
- Grounding terminal screw standard
- Receptacles have triple wire line contacts and double wipe ground contacts to insure long term plug retention
- THK steel mounting strap zinc plated for corrosion-resistance
- Break-off provision for wiring both devices on same circuit or on separate circuits
- Terminal screws backed out ready for wiring
- Side wire terminals accept up to 10 AWG solid or stranded wire
- Pilot light may be wired to indicate power On or power Off
- Combination slot Phillips® head mounting and terminal screws ease installation
- Thermoplastic top and back body are virtually unbreakable
- Mounting straps are zinc plated to for added corrosion-resistance
- Heavy duty brass contact
- Red lexan pilot lens, neon lamp
| Dimensions | 4.19 in H x 1.37 in W x 0.95 in D |
|---|---|
| Voltage Rating | 120 VAC |
| Temperature Rating | -20 to 60 deg C |
| Mounting | Wall |
| Color | Brown |
| Type | 3-Way Duplex |
| Number of Poles | 1 |
| Material | Thermoplastic |
| Terminal Type | Screw |
| Amperage Rating | 15 A |
| Brand | Eaton |
| Amperage | 15 Amp |
| Type | Switches & Lights |
| Voltage | 120V |
| Color | Brown |
