EATON AH1222B
INDUSTRIAL GRADE 20A SW
SKU
676560
EATON Arrow Hart™ Toggle Switch, Automatic Grounding Premium Specification Grade, Series: AH1220, 120/277 VAC, 20 A, 1 hp Power, 2 Pole, Toggle Actuator, Wall Mounting, Screw Terminal, 30000 Cycles Operating Cycles, Polycarbonate, Brown, Environmental Conditions: -4 to 140 deg F Operating Temperature, 3.28 in H x 1.31 in W x 1.05 in D Dimensions
- Color coded faces identify amperage
- 14 to 10 AWG terminal accommodation
- Nylon toggle
- 2.4 in L screw to screw
- 1 hp at 120 VAC, 2 hp at 240 VAC
| Dimensions | 3.28 in H x 1.31 in W x 1.05 in D |
|---|---|
| Power Rating | 1 hp |
| Voltage Rating | 120/277 VAC |
| Operating Cycles | 30000 Cycles |
| Series | AH1220 |
| Mounting | Wall |
| Environmental Conditions | -4 to 140 deg F Operating Temperature |
| Color | Brown |
| Type | Automatic Grounding Premium Specification Grade |
| Number of Poles | 2 |
| Material | Polycarbonate |
| Terminal Type | Screw |
| Amperage Rating | 20 A |
| Actuator | Toggle |
| Brand | Eaton |
| Amperage | 20 Amp |
| Type | Toggle |
| Voltage | 120/277V |
| Color | Brown |
