Eaton Wiring Devices CWL515C-C
2P 3W 15A 125V TWIST LOCK CONN
SKU
770273
Eaton Wiring Devices Safety Gripâ„¢ Safety Grip Connector, Polarized Grounding, 125 VAC, 15 A, 2 Pole, 3 Wires, NEMA L5-15R NEMA Rating, Industrial Grade, 0.25 to 0.656 in Diameter Cord, -40 to 75 deg C, Back Wire Terminal, Nylon, Black/White, 1.5 in Dia x 2.87 in L Dimensions
- Neoprene gasket seals cord hole from dust and debris
- Back wired dead front design
- Individual wiring compartments with tapered channel for easy insertion of wires
- Dual range cord grip provides solid cord clamp
- Back wire terminal clamps for easy secure wiring
- Combination head screws standard slot/Phillips in the U.S
- Canadian screws slot/Robertson head combination
- Clear cover over wiring compartments allow easy inspection of wiring terminations
- 16 - 12 AWG terminal accommodation
- Meets UL94 requirements, V2 rated flammability
- Current interrupting rated
- Maximum 30 deg C after 200 cycles of overload temperature rise
- Nylon outer shell, interior body and cord clamp, polycarbonate terminal retainer, brass blades and line contacts, steel terminal clamps
- NO 10-32 brass, neutral screw nickel plated terminal screws, NO 10-32 brass (green) ground screw
- Steel, Zinc plated assembly screws and cord clamp screws, neoprene gasket/dust shield
- Industrial specification grade
| Grade | Industrial |
|---|---|
| Number of Poles | 2 |
| Color | Black/White |
| Type | Polarized Grounding |
| Dimensions | 1.5 in Dia x 2.87 in L |
| Amperage Rating | 15 A |
| Number of Wires | 3 |
| Cord Diameter | 0.25 to 0.656 in |
| Voltage Rating | 125 VAC |
| Temperature Rating | -40 to 75 deg C |
| Material | Nylon |
| Terminal Type | Back Wire |
| NEMA Rating | NEMA L5-15R |
| Brand | Cooper Wiring Devices |
