Danfoss 013G8020
3/4" STRAIGHT DANFOSS VALVE
SKU
391091
Danfoss Thermostatic Radiator Valve, Straight, Series: RA 2000, 3/4 in Nominal, MNPT x FNPT End Style, 145 psi (Static)/232 psi (Test) Pressure, 250 deg F, Brass Body, EPDM Disc, Seat Washer O-Ring Softgoods, Nickel Plated
- Valve bodies are designed to meet the demands of the residential, commercial and industrial sectors
- 140 deg F max sensor temperature
- 15 psi maximum differential pressure (water)
- 45 to 86 deg F adjustable temperature range
- RA 2000 valves are fitted with a packing gland assembly that is replaceable while the system is in operation
- Sturdy EPDM rubber valve disc provides a seal against the valve seat at differential pressures of up to 15 PSI in hot water heating systems, while 15 psig for low pressure steam systems
- Manual plastic cap supplied to protect the valve pushpin and provide manual control of the valve during installation
- If manual operation is required, a separate version of manual knob is available
- Valves remain normally open with no operator mounted
- 2.7 CV
- FPT x MPT union tailpiece connection
| Finish | Nickel Plated |
|---|---|
| Softgoods Material | EPDM Disc, Seat Washer O-Ring |
| End Style | MNPT x FNPT |
| Body Material | Brass |
| Nominal Size | 3/4 in |
| Type | Straight |
| Pressure Rating | 145 psi (Static)/232 psi (Test) |
| Temperature Rating | 250 deg F |
| Series | RA 2000 |
| Brand | Danfoss |
