American Standard 7025205.002
BATTERY OPER.0.5 GPM FAUCET
SKU
882254
American Standard SmarTherm™ Faucet, Base Model, Series: 605B.165, Selectronic® Collection, 1 gpm Flow Rate, Gooseneck Swivel Rigid Spout, 6-1/8 in Spout Reach, 7 in Spout Height, 18 in Hose, 1 Faucet Hole, 3/8 in Connection, Compression Connection, Spray Pattern: Multi-Laminar, Function: Touchless, 2 in Maximum Deck Thickness, Deck Mounting, Self-Cleaning Solenoid, 2 in D x 11-1/8 in H Dimensions, Cast Brass, Polished Chrome, Commercial
- 0.5 gpm pressure compensating, vandal-resistant multi-laminar spray
- CR-P2 lithium battery pre-installed in the faucet
- Above deck mixing - allows user to manually adjust temperature
- Red/blue indicator ring
- Removable mixing handle - installer can set temperature and remove handle to prevent user adjustment
- Dual inlets - for hot and cold water
- Check valves included to prevent cross flow
- Filter assembly protects the solenoid valve from debris
- Hygienic, touch-free operation
- Clean, integrated design - all electronics contained in faucet spout
- No control box below deck
- Easy installation and maintenance - faucet installs from the top
- All serviceable parts are easily accessible
- Flexible Selectronic® platform with programmable sensor and interchangeable power supplies
- Self-cleaning solenoid reduces maintenance - integral wiper spring prevents clogging and run-on
- Fail-safe - faucet automatically shuts off upon loss of power or dead battery
- No reset required
- Auto purge - periodically purges stagnant water from faucet and supply lines
| Material | Cast Brass |
|---|---|
| Connection Size | 3/8 in |
| Spout Height | 7 in |
| Flow Rate | 1 gpm |
| Connection Type | Compression |
| Mounting Type | Deck |
| Spout Type | Gooseneck Swivel Rigid |
| Hose Size | 18 in |
| Number of Faucet Holes | 1 |
| Maximum Deck Thickness | 2 in |
| Spray Pattern | Multi-Laminar |
| Function | Touchless |
| Dimensions | 2 in D x 11-1/8 in H |
| Series | 605B.165 |
| Finish | Polished Chrome |
| Commercial/Residential | Commercial |
| Collection | Selectronic® |
| Finish/Color | Polished Chrome |
| Spout Reach | 6-1/8 in |
| Valve/Cartridge Type | Self-Cleaning Solenoid |
| Domestic/Import | Import |
| Type | Base Model |
| Brand | American Standard |
