Grundfos 59896771
GRUNDFOS UP15-29SF SS CIRC
SKU
392034
Grundfos Circulator Pump, Series: UP Series, 20.7 gpm, 9.843 ft Maximum Head, 87 W, 115 VAC, 0.75 A, 60 Hz, 1 ph, 145 psi Maximum, 104 deg F, 5-8/16 in W x 6-8/16 in H
- Ceramic shaft and radial bearings
- Carbon axial bearing
- Stainless steel rotor can and bearing plate
- Corrosion resistant impeller, composite, PES
- Stainless steel pump housing
- 1 ph motor, no additional motor protection is required
| Voltage Rating | 115 VAC |
|---|---|
| Power Rating | 87 W |
| Maximum Pressure | 145 psi |
| Maximum Head | 9.843 ft |
| Amperage Rating | 0.75 A |
| Phase | 1 ph |
| Temperature Rating | 104 deg F |
| Dimensions | 5-8/16 in W x 6-8/16 in H |
| Series | UP Series |
| Flow Rate | 20.7 gpm |
| Frequency Rating | 60 Hz |
| Brand | Grundfos |
