Grundfos 96160175
GRUNDFOS SQE 5GPM 1/2HP 230V
SKU
321576
Grundfos, 96160175, Submersible Pump, Series: SQE, 4.4 gpm Flow Rate, 2 Wires, 4 Stage, 1/2 hp Power, 200/240 VAC, 5.2 A, 50/60 Hz Frequency, 1 ph, 10700 rpm Motor, Floating Impeller, 68 deg F, IP68 Enclosure, Thrust Bearing, Stainless Steel
- Soft start - Prevents water hammer and motor overheating
- Dry run protection - Pumps are water lubricated and if your well runs low, an unprotected pump will die
- Overload protection - If a pump becomes clogged with debris like sand or grass, it can destroy an unprotected motor
- Over and under voltage protection - The lifetimes of unprotected motors can be greatly reduced by improper voltages
- Push button pressure set point adjustment
- Low well water indicator
- Pump running indicator
- Keypad lockout
- High quality stainless steel pressure sensor
- Built-in diagnostics
- High pump and motor efficiency
- Wear resistance
- Basic version with electronic communication
| Impeller Type | Floating |
|---|---|
| Power Rating | 1/2 hp |
| Flow Rate | 4.4 gpm |
| Power Rating | 1/2 hp |
| Amperage Rating | 5.2 A |
| Temperature Rating | 68 deg F |
| Voltage Rating | 200/240 VAC |
| Voltage Rating | 200/240 VAC |
| Series | 5 SQE05-180 |
| Frequency Rating | 50/60 Hz |
| Series | SQE |
| Number of Wires | 2 |
| Phase | 1 ph |
| Material | Stainless Steel |
| Number of Stages | 4 |
| Motor Speed | 10700 rpm |
| Material | Stainless Steel |
| Impeller Type | Floating |
| Bearing Type | Thrust |
| Enclosure Type | IP68 |
| Motor Speed | 10700 rpm |
| Phase | 1 ph |
| Enclosure Type | IP68 |
| Frequency Rating | 50/60 Hz |
| Temperature Rating | 68 deg F |
| Flow Rate | 4.4 gpm |
| Brand | Grundfos |
