Siemens G80-424
100A 600V 3P LV SAFETY SWITCH
SKU
708660
Siemens Safety Switch, Enclosed Heavy Duty Non-Fusible, 480/600 VAC, 100 A, 75 hp at 480 VAC, 100 hp at 600 VAC, 3 ph, 60 Hz Frequency, 3 Pole, 3 Wires, Single Throw Actuator, NEMA 3R Enclosure, 2/3-Point Mounting Hole Mounting, -20 to 120 deg F, 21.95 in H x 9.64 in W x 5.05 in D Dimensions, 304 Stainless Steel
- Padlocking provision for lock out in Off position
- Lugs suitable for copper or aluminum 60 or 70 deg C rated wire
- For use with cartridge type fuses, also used for 2-pole applications
- Suitable for use as service entrance equipment
| Material | 304 Stainless Steel |
|---|---|
| Dimensions | 21.95 in H x 9.64 in W x 5.05 in D |
| Number of Poles | 3 |
| Short Circuit Current Rating | 200 kA |
| Insulation Type | Non-Insulated |
| Actuator Type | Single Throw |
| Frequency Rating | 60 Hz |
| Enclosure Type | NEMA 3R |
| Phase | 3 |
| Mounting Type | 2/3-Point Mounting Hole |
| Type | Enclosed Heavy Duty Non-Fusible |
| Contact Form | TPST |
| Voltage Rating | 480/600 VAC |
| Horsepower | 75 hp at 480 VAC, 100 hp at 600 VAC |
| Temperature Rating | -20 to 120 deg F |
| Amperage Rating | 100 A |
| Number of Wires | 3 |
| Terminal Type | Lug |
| Brand | Siemens Ind |
