BURNDY K2A25U
TWO:14 STR-1/0 STR DUAL
SKU
805857
BURNDY® Mechanical Bolted Lug and Terminal, Dual Rated Universal, Series: K2A-U, Copper/Stranded Aluminum Conductor, 14 to 1/0 AWG Conductor, 1/4 in Stud, 1 Bolt Hole, 1.15 in W x 0.19 in THK Tongue, Straight Tongue, Specifications: 0.79 in H x 1.13 in W Collar, (2) Slotted Screw, 50 in-lb Installation Torque, 2-Conductor, 194 deg F, Aluminum, Electro-Zinc Plated, 1.47 in L x 0.79 in H Dimensions
- Dual rated panelboard lugs are constructed from high strength extruded aluminum alloy and electro tin plated to provide low contact resistance
| Temperature Rating | 194 deg F |
|---|---|
| Dimensions | 1.47 in L x 0.79 in H |
| Specifications | 0.79 in H x 1.13 in W Collar, (2) Slotted Screw, 50 in-lb Installation Torque, 2-Conductor |
| Conductor Size | 14 to 1/0 AWG |
| Stud Size | 1/4 in |
| Conductor Type | Copper/Stranded Aluminum |
| Series | K2A-U |
| Tongue Size | 1.15 in W x 0.19 in THK |
| Tongue Type | Straight |
| Material | Aluminum |
| Number of Bolt Holes | 1 |
| Type | Dual Rated Universal |
| Finish | Electro-Zinc Plated |
| Brand | Burndy LLC |
