Powers™ HydroGuard® XP Master Tempering Valve, High/Low, Series: LFSH1430, 2 in Nominal, NPT, 125 psi, 5 to 200 deg F, 201 gpm, Media: Water, Brass Body, Polished Chrome, 19-1/4 in L, Domestic
- 201 GPM (761 LPM)Valve capacity at 45 psi
- 2 in NPT Connection
- Advanced thermal actuator
- Mounts in any position
- Dirt and lime resistant poppet and seat design
- Rotatable union triple-duty checkstops
- Vandal-resistant, locking mechanism to secure temperature setting
- Virtual shutoff if supply pressure fails
- The wetted surface of this product contacted by consumable water contains less than 0.25% of lead by weight
- 90 to 160 deg F adjustment temperature
| Nominal Size | 2 in |
|---|---|
| Finish | Polished Chrome |
| Body Material | Brass |
| Media | Water |
| Domestic/Import | Domestic |
| Dimensions | 19-1/4 in L |
| Pressure Rating | 125 psi |
| Flow Rate | 201 gpm |
| Type | High/Low |
| Series | LFSH1430 |
| Temperature Rating | 5 to 200 deg F |
| End Style | NPT |
| Brand | Powers |
