Mersen 30311
1P 600V MOUNT FUSEHOULDER
SKU
775614
Mersen Fuse Block, Open Style, Series: 303, 600 VAC/VDC, 30 A, 1 Pole, 1 ph, Class: Midget, Screw with Double Quick-Connect Connection, 14 to 10 AWG Wire, DIN Rail/Threaded Mounting, 1-1/2 in Fuse Length, 13/32 in Diameter Fuse, 125 deg C, For Use With: ATQ, ATM, A6Y-2B, A25Z-2, TRM, OTM, A15QS-2, GFN, GGU, A60Q-2, DCT Series Fuse, Glass Reinforced Polycarbonate, 0.85 in W x 1.31 in D x 3.04 in H Dimensions
- 20 in-lb torque rating
- Tin-plated copper contact
| Dimensions | 0.85 in W x 1.31 in D x 3.04 in H |
|---|---|
| Wire Size | 14 to 10 AWG |
| Number of Poles | 1 |
| Amperage Rating | 30 A |
| Mounting Type | DIN Rail/Threaded |
| Material | Glass Reinforced Polycarbonate |
| Suitable For Use With | ATQ, ATM, A6Y-2B, A25Z-2, TRM, OTM, A15QS-2, GFN, GGU, A60Q-2, DCT Series Fuse |
| Voltage Rating | 600 VAC/VDC |
| Fuse Diameter | 13/32 in |
| Temperature Rating | 125 deg C |
| Number of Phases | 1 |
| Connection Type | Screw with Double Quick-Connect |
| Type | Open Style |
| Class | Midget |
| Series | 303 |
| Fuse Length | 1-1/2 in |
| Brand | Merson Fuses |
