Mersen A15QS30-2
30A 150V FUSE TYPE QS
SKU
706690
Mersen AMP-TRAP® High Speed Fuse, Round Style Semi-Conductor, Series: A15QS, Non-Rejection, 30 A, 150 VAC, 50/100 kA Interrupt, 10 ms Response, Ferrule Terminal, Clip Mounting, Cylindrical/Round Body, Ceramic/GMG, 0.41 in Dia x 1.5 in L Body
- Low i2t minimizes damage to protected components on short circuit
- Controlled arc voltage reduces stress to circuit components during fuse clearing
- Choice of mounting types provides options for unique termination requirements
- Fast acting
- Current limiting
- 100 kA at 150 VAC, 50 kA at 150 VDC interrupt rating
| Body Type | Cylindrical/Round |
|---|---|
| Voltage Rating | 150 VAC |
| Type | Round Style Semi-Conductor |
| Rejection/Non-Rejection | Non-Rejection |
| Amperage Rating | 30 A |
| Interrupt Rating | 50/100 kA |
| Material | Ceramic/GMG |
| Terminal Type | Ferrule |
| Mounting Type | Clip |
| Response Time | 10 ms |
| Body Size | 0.41 in Dia x 1.5 in L |
| Series | A15QS |
| Brand | Merson Fuses |
