MORRIS 94020
1/2 STACKING (2) 14/2
SKU
683111
MORRIS Compression Lug, 1-Hole, Stranded Copper Conductor, 6 AWG Conductor, 35 kV, 5/16 in Stud, 0.67 in L x 0.42 in W x 0.08 in THK Tongue, 1-1/2 in Overall Length, Short Barrel, 0.204 in ID x 0.295 in OD x 0.71 in L Barrel, 90 deg C, 0.33 in Mounting Hole, Copper, Blue
- 1-hole compression lugs are made of high conductivity seamless electrolytic copper
- Uniform bright electro tin plating resists corrosion, reduces contact resistance and gives you maximum conductivity
- Crimp marks indicate proper crimp locations
- Peephole for verification of proper strand insertion
- Listed for 35 kv when properly installed
- Single Mounting Hole
| Mounting Hole Size | 0.33 in |
|---|---|
| Conductor Type | Stranded Copper |
| Conductor Size | 6 AWG |
| Type | 1-Hole |
| Color | Blue |
| Voltage Rating | 35 kV |
| Barrel Type | Short |
| Tongue Size | 0.67 in L x 0.42 in W x 0.08 in THK |
| Overall Length | 1-1/2 in |
| Barrel Size | 0.204 in ID x 0.295 in OD x 0.71 in L |
| Temperature Rating | 90 deg C |
| Stud Size | 5/16 in |
| Material | Copper |
| Brand | Morris |
