MORRIS 97020
2/0 INSULATED SPLICE
SKU
685405
MORRIS Mechanical Insulated Connector, In-Line, Aluminum/Copper Conductor, 6 to 2/0 AWG Conductor, 600 VAC, 3/16 in Allen Hex, Clear PVC Insulation, -49 to 194 deg F, 6061-T6 Aluminum, 3.55 in L x 0.96 in W x 2.05 in H
- 6061-T6 aluminum CU9AL dual-rated for use with copper and/or aluminum wires
- Insulated splice with rugged high dielectric rubber/vinyl coating
- Pre-filled with oxide inhibitor
- Insulated splice provides easy re-entry for changes, inspection or troubleshooting
- Plugs marked with connector max wire size for easy identification
- 1-wire per terminal
- Insulated Electrical Power Connector In-Line Splice
- Black Insulated Splice for easy fast hassle free installations
| Conductor Type | Aluminum/Copper |
|---|---|
| Conductor Size | 6 to 2/0 AWG |
| Type | In-Line |
| Dimensions | 3.55 in L x 0.96 in W x 2.05 in H |
| Voltage Rating | 600 VAC |
| Specifications | 3/16 in Allen Hex, Clear PVC Insulation |
| Temperature Rating | -49 to 194 deg F |
| Material | 6061-T6 Aluminum |
| Brand | Morris |
