NSI WWC-Y-C
YELLOW WING WIRE NUT EASY TWIS
SKU
819533
NSI Easy-Twist™ Twist-On Wire Connector, Series: WWC, Swept Back Winged Shell Style, Fixed/Square Wire Spring, Copper Wire, 18 to 10 AWG Wire, 600 VAC, Specifications: 1 Conductor, 0.252 in Dia Top, 105 deg C, Thermoplastic, Yellow, 1.01 in H x 0.717 in W
- Flame retardant UL 94V-2 thermoplastic shell that provides excellent electrical insulation
- Easy-twist winged twist-on wire connectors have deep surface ridges to provide better grip
- Fixed, precise square wire spring provides secure gripping of conductors
- Deep skirt entry provides protection from flashover and shorts
- 1000 V maximum in fixtures and signs
- Compact design ensures proper installation, especially in tight spaces
- Threaded funnel entry guides the wires into the connector easily
- Pre-twisting of wires is not necessary
- Zinc plated springs for low contact resistance
- (2) 18 to (3) 12 AWG wire combinations
| Temperature Rating | 105 deg C |
|---|---|
| Color | Yellow |
| Dimensions | 1.01 in H x 0.717 in W |
| Spring Type | Fixed/Square Wire |
| Specifications | 1 Conductor, 0.252 in Dia Top |
| Wire Type | Copper |
| Shell Style | Swept Back Winged |
| Voltage Rating | 600 VAC |
| Series | WWC |
| Material | Thermoplastic |
| Wire Size | 18 to 10 AWG |
| Brand | NSI Ind |
