Oatey® MODA™ Air Admittance Valve Box, Specifications: 20 DFU, PVC, 8 in W x 3.38 in D x 4.85 in H, Domestic
- Using a single box platform provides significant convenience to installers
- One universal faceplate is compatible with all box types
- All boxes can snap to one another and common brackets can be used on any MODA™ supply box
- Unique interlocking wing flanges accommodate on-stud, straddle stud and three box installations
- Advanced snap-lock design allows assembly and disassembly with equal ease for quicker installation and easy repositioning on the job
- Separate valve and drain boxes allow paired or split boxes between walls or stud bays to prevent supply/drain crossovers
- Dual box design provides ideal options for stacked washer/dryers and space limited laundry rooms
- Plumber preferred, quarter turn test plug with gasket provided with every drain box
- This means no knock outs falling into drains and no tools required
- Oatey® exclusive feature
- Stands upto the roughest job site abuse and no transition cement needed when solvent welding PVC pipe
- 2-piece valve design makes valve replacement easy-to-repair, without damaging drywall
- Valves rated to 150 psi air and 250 psi water
- PVC with 2 in NPT threads valve
- PVC 1/4 turn adapter with sealing gasket
- Faceplates are pre-assembled on box
| Domestic/Import | Domestic |
|---|---|
| Dimensions | 8 in W x 3.38 in D x 4.85 in H |
| Specifications | 20 DFU |
| Material | PVC |
| Brand | Oatey |
