Packard 60825F
HIGH TEMP CFM 1/6HP 208-230
SKU
876001
Packard Vulcan70C™ Condenser Fan Motor, High Temperature, Application Type: Condenser Fan Motors, 1/6 hp, 208 to 230 VAC, 1 to 1.1 A, 825 rpm, 1 Speed, 1/2 in Dia x 6-1/2 in L Shaft, Reversible, Ball Bearing, Extended Thru-Bolt Mount, 70 deg C Ambient, Insulation Class: Class F
- Designed for condenser fan and heat pump units requiring vertical shaft-up or vertical shaft down positioning with belly band or extended clamp screw mounting
- Drilled and tapped holes in the shell for Rheem® mounting
- All-angle mount
- Energy efficient PSC design
- 36 in L lead
- 5 uF at 370 VAC capacitor required
| Type | High Temperature |
|---|---|
| Mounting Type | Extended Thru-Bolt |
| Insulation Class | Class F |
| Application Type | Condenser Fan Motors |
| Speed | 825 rpm |
| Horsepower | 1/6 hp |
| Rotation | Reversible |
| Bearing Type | Ball |
| Shaft Size | 1/2 in Dia x 6-1/2 in L |
| Number of Speeds | 1 |
| Voltage Rating | 208 to 230 VAC |
| Amperage Rating | 1 to 1.1 A |
| Temperature Rating | 70 deg C Ambient |
| Brand | Packard Inc |
