Apollo 94A10901
APOLLO 21/2 THD 600# FP BV
SKU
354942
Apollo™, 94A10901, Ball Valve, 2-Piece, Series: 94A, 2-1/2 in Nominal, FNPT End Style, 400 psi CWP Pressure, 0 to 400 deg F, Full Port, Media: Gas, Lever Operated Actuator, 5.38 in Inlet to Outlet Length, 4.65 in Top to Inlet Center, Chrome Plated Brass Stem/PTFE Seat Trim, PTFE Softgoods
- Blow-out proof stem
- Adjustable stem packing nut
- Silicone free
- 100% factory tested
- Forged brass (Cu >57 percent) retainer
- Brass gland nut
- Corrosion resistant plated steel handle and nut
- 2-1/4 in memory stop option
| Softgoods Material | PTFE |
|---|---|
| Port Type | Full |
| End Style | FNPT |
| Media | Gas |
| Ball Material | Chrome Plated Brass |
| Inlet to Outlet Length | 5.38 in |
| Top to Inlet Center | 4.65 in |
| Type | 2-Piece |
| Pressure Rating | 400 psi CWP |
| Body Material | Brass |
| Nominal Size | 2-1/2 in |
| Temperature Rating | 0 to 400 deg F |
| Series | 94A |
| Actuator Type | Lever Operated |
| Trim Material | Chrome Plated Brass Stem/PTFE Seat |
| Brand | Apollo/Conbraco |
| Size | 2 1/2" |
