Mersen ATDR20
20A 600V FUSE CLASS CC
SKU
676830
Mersen AMP-TRAP® 2000 SmartSpot® Power Fuse, Current Limiting North American Time Delay, Series: ATDR, Non-Indicating, Rejection, 20 A, 600 VAC, 200 kA Interrupt, Class: CC, Ferrule Terminal, Clip Mounting, Cylindrical Body, Dual Element, Fiberglass, 13/32 in Dia x 1-1/2 in L Body
- Time delay for motor starting inrush currents without nuisance opening
- Highly current limiting for low peak let through current
- Improved cycling ability for frequent motor starts/stops without nuisance fuse opening
- Rejection style design prevents replacement errors (when used with recommended fuse blocks)
- High visibility orange label ensures instant brand recognition, simplifies replacement
- Metal embossed date and catalog number for traceability and lasting identification
- Fiberglass body provides dimensional stability in harsh industrial settings
- High grade silica filler ensures fast arc quenching and optimum current limitation
- Tin-plated copper contact
| Interrupt Rating | 200 kA |
|---|---|
| Body Type | Cylindrical |
| Element | Dual |
| Body Size | 13/32 in Dia x 1-1/2 in L |
| Voltage Rating | 600 VAC |
| Terminal Type | Ferrule |
| Type | Current Limiting North American Time Delay |
| Class | CC |
| Rejection/Non-Rejection | Rejection |
| Material | Fiberglass |
| Indicating/Non-Indicating | Non-Indicating |
| Series | ATDR |
| Mounting Type | Clip |
| Amperage Rating | 20 A |
| Brand | Merson Fuses |
| Voltage | 600V |
