Edwards Signaling 270-SPO
SP FIREALARM STATION
SKU
707494
Edwards Signaling™ Fire Alarm Pull Station, Conventional Single Action, Series: 270, 30 VAC, 60 VDC, 3 A, 4-1/2 in Height, 3-1/4 in Width, 2-1/2 in Depth, 32 to 120 deg F, Specifications Met: CSFM, FM Approved, MEA Listed, UL Listed, Die Cast Metal, Flush Mounting, Red
- Terminal strip wiring
- Break glass type
| Width | 3-1/4 in |
|---|---|
| Color | Red |
| Depth | 2-1/2 in |
| Height | 4-1/2 in |
| Type | Conventional Single Action |
| Voltage Rating | 30 VAC, 60 VDC |
| Material | Die Cast Metal |
| Mounting Type | Flush |
| Amperage Rating | 3 A |
| Temperature Rating | 32 to 120 deg F |
| Series | 270 |
| Specifications Met | CSFM, FM Approved, MEA Listed, UL Listed |
| Brand | Edwards Signaling |
