Square D EGB34020
3P 20A SQ-D BREAKER 480V
SKU
903728
Square D™ Square D™ Miniature Circuit Breaker, Molded Case Standard, 277/480Y VAC, 20 A, 50/60 Hz Frequency, 35 kA Interrupt, E Frame, Thermal Magnetic Trip, 270 to 875 A Trip, 3 Pole, 3 ph, Lug Connection, 12 to 6 AWG, 14 to 6 AWG Wire, Bolted-On Mounting, 104 deg F, 4.05 in L x 2.94 in W x 5.66 in H Dimensions
- Visi-Trip™ trip indicator
- 270 A hold, 875 A trip
- For merchandised NF panelboards
- 12 to 6 AWG Al, 14 to 6 AWG Cu wire
| Phase | 3 ph |
|---|---|
| Wire Size | 12 to 6 AWG, 14 to 6 AWG |
| Type | Molded Case Standard |
| Frequency Rating | 50/60 Hz |
| Temperature Rating | 104 deg F |
| Frame | E |
| Number of Poles | 3 |
| Connection Type | Lug |
| Mounting Type | Bolted-On |
| Dimensions | 4.05 in L x 2.94 in W x 5.66 in H |
| Interrupt Rating | 35 kA |
| Amperage Rating | 20 A |
| Trip Type | Thermal Magnetic |
| Trip Range | 270 to 875 A |
| Voltage Rating | 277/480Y VAC |
| Brand | Square D Co |
