Grundfos 59896121
GRUNDFOS UP15-18B7 BRNZ 3/4CC
SKU
255145
Grundfos, 59896121, Circulator Pump, Canned Rotor, Series: UP Series, 3/4 in C Inlet, 3/4 in C Outlet, 13.78 ft Maximum Head, 85 W Power, 115 VAC, 0.74 A, 60 Hz Frequency, 1 ph, 145 psi Maximum, Composite PES Impeller, 140 deg F, Radial/Thrust Bearing, 5-1/8 in W x 6-3/8 in H Dimensions
- Ceramic shaft, radial bearings and carbon thrust bearing
- Stainless steel rotor can and bearing plate
- Impeller of corrosion-resistant material
- No additional motor protection is required
- Non-electronically controlled circulator pumps for domestic building with speed control
- Bronze pump housing
- Small stator
- 1-speed motor
| Voltage Rating | 115 VAC |
|---|---|
| Power Rating | 85 W |
| Bearing Type | Radial/Thrust |
| Maximum Pressure | 145 psi |
| Maximum Head | 13.78 ft |
| Type | Canned Rotor |
| Amperage Rating | 0.74 A |
| Phase | 1 ph |
| Inlet Size | 3/4 in C |
| Temperature Rating | 140 deg F |
| Dimensions | 5-1/8 in W x 6-3/8 in H |
| Series | UP Series |
| Impeller Type | Composite PES |
| Outlet Size | 3/4 in C |
| Frequency Rating | 60 Hz |
| Brand | Grundfos |
