Legrand PS4100P12W
100A 4 WIRE 250V MALE PLUG
SKU
887139
Pass & Seymour® Pin and Sleeve Plug, 3-Phase Watertight, 125/250 VAC, 100 A, 60 to 400 Hz, 3 Pole, 4 Wires, Commercial Grade, -50 to 80 deg C, Screw Terminal, Thermoplastic, Black, 15 in
- All P and S watertight pin and sleeve plugs, connectors, receptacles and inlets bring you the features to enhance versatility, reliability and safety
- North American products come completely ready to wire, for quick, simple installation
- All feature chemical-resistant thermoplastic construction
- Shrouded, nickel plated, solid brass pins provide corrosion protection and excellent conductivity
- An exclusive, hinged cord-grip eliminates loose parts that get lost
- Arrives ready to wire, with cord-grip open and cable ready
- Nylon construction for high impact and corrosion-resistance
- Locking ring with an integral neoprene gasket provides watertight seal when plug and connector/receptacle are mated
- Natural rubber grommets provide watertight protection at cable entry
- Combination head screws for added convenience and quick installation
- Revolutionary, hinged cord-grip for durable performance and ease of installation
- Cover with integral neoprene gasket provides watertight seal
- Moisture resistant
- UV resistant
- 3000 VAC maximum dielectric strength voltage
| Grade | Commercial |
|---|---|
| Number of Poles | 3 |
| Color | Black |
| Type | 3-Phase Watertight |
| Dimensions | 15 in |
| Amperage Rating | 100 A |
| Number of Wires | 4 |
| Voltage Rating | 125/250 VAC |
| Temperature Rating | -50 to 80 deg C |
| Material | Thermoplastic |
| Terminal Type | Screw |
| Frequency Rating | 60 to 400 Hz |
| Brand | Pass & Seymour |
