Leviton® Photocell, 24 VDC, 10 mA, 0 to 250 fc Sensitivity, IP54 Enclosure, Environmental Conditions: -11 to 60 deg C Operating Temperature, 20% to 90% Non Condensing Humidity, Stem Mounting, White, 1.28 in Dia x 1.85 in H Dimensions
- Constant lighting at the optimal level for greater visual comfort and acuity, which contributes to improved productivity
- Provides convenient, automatic hands free daylight harvesting when integrated with Leviton® lighting control products
- Lowers electric bills by reducing usage of lighting where ambient natural light is also present
- Lumen maintenance opportunity compatible
- Outdoor photocells are IP54 rated to guarantee ultimate protection from dirt, dust, oil and other non-corrosive material
- Measures light from any source in the visible spectrum within a 60 deg cone or 180 deg angle of response depending on the model
- PCOUT outdoor photocell is enclosed in a weatherproof housing with a visor for shading and lens protection, default setting 0 to 250 FC sensing range
| Sensitivity | 0 to 250 fc |
|---|---|
| Voltage Rating | 24 VDC |
| Amperage Rating | 10 mA |
| Color | White |
| Mounting Type | Stem |
| Environmental Conditions | -11 to 60 deg C Operating Temperature, 20% to 90% Non Condensing Humidity |
| Dimensions | 1.28 in Dia x 1.85 in H |
| Enclosure Type | IP54 |
| Brand | Leviton Mfg |
