Simpson Strong-Tie SL50214C
*1/2"X21/4" ROD COUPLER SIMPSO
SKU
607948
Simpson Strong-Tie® Sleeve Anchor, Pre-Assembled Expanding, Series: Sleeve-All®, 1/2 in Diameter, Carbon Steel, Rod Coupler Head, Zinc Plated, 2-1/4 in Minimum Embedment Depth, 2-1/4 in Overall Length, 1/2 in Drill, 1250 lb at 2000 psi Shear Strength, 790 lb at 2000 psi Tensile Strength
- Accepts 1/2 in Dia rod
- Material meets minimum 50000 psi tensile anchor body
- SAE J403, grade 1008 cold rolled steel sleeve
- Commercial grade nut, meets requirements of ASTM A563 grade A
- SAE J403, grade 1008/1010 cold rolled steel washer
- 5 in critical edge distance
- 9 in critical spacing distance
- 3160 lb at 2000 psi ultimate tension load for concrete
- 4760 lb at 4000 psi ultimate tension load for concrete
- 5000 lb at 2000 psi ultimate shear load for concrete
- 25 ft-lb install torque
- 1190 lb at 4000 psi for concrete
| Finish | Zinc Plated |
|---|---|
| Shear Strength | 1250 lb at 2000 psi |
| Minimum Embedment Depth | 2-1/4 in |
| Series | Sleeve-All® |
| Head Type | Rod Coupler |
| Overall Length | 2-1/4 in |
| Diameter | 1/2 in |
| Material | Carbon Steel |
| Tensile Strength | 790 lb at 2000 psi |
| Type | Pre-Assembled Expanding |
| Drill Size | 1/2 in |
| Brand | Simpson Strong-Tie |
