HAYWARD TB2100STE
1" TRUE UNION BALL VLV CPVC
SKU
346214
HAYWARD® True Union Ball Valve, Series: TB Series, 1 in Nominal, Socket/Thread End Style, 250 psi Pressure, 34 to 180 deg F, Full Port, T-Handle Actuator, CPVC Ball, 5.44 in Inlet to Outlet Length, 3.26 in Top to Inlet Center, CPVC Body, PTFE Seat Trim, EPDM Softgoods
- All true union ball valves are assembled with silicone free lubricant and have PTFE seats
- For actuator-ready
- EPDM O-ring
| End Style | Socket/Thread |
|---|---|
| Body Material | CPVC |
| Pressure Rating | 250 psi |
| Inlet to Outlet Length | 5.44 in |
| Softgoods Material | EPDM |
| Ball Material | CPVC |
| Top to Inlet Center | 3.26 in |
| Series | TB Series |
| Trim Material | PTFE Seat |
| Temperature Rating | 34 to 180 deg F |
| Actuator Type | T-Handle |
| Port Type | Full |
| Nominal Size | 1 in |
| Brand | Hayward |
| Size | 1" |
| Type | Valves |
