Uponor Q2110400
4 OUT W 1/2" PX EP VLVD MFLD
SKU
461254
Uponor Manifold Kit D, EP Valved, 4 Outlets, 1/2 in ProPEX Outlet, 150 psi, 210 deg F, Polyphenylsulfone, 9 in L x 3.93 in H
- 320 deg F maximum temprature at no pressure
- 15 gpm flow at 5 fps
- 31 gpm Flow at 8 fps
- The EP valved manifold is available with three or four ProPEX® outlets
- The EP valved manifold is suitable for hot- and cold-water distribution systems
- The manifolds can be joined to other EP valved manifolds using manifold couplings, and can be supplied with 3/4 or 1 in ProPEX inlets
- Do not use thread sealant on connections
- Carriers present in these compounds can crack the plastic port connections, resulting in leaks and water damage
- Any bend within 6 inches of the ProPEX connection to the manifold requires the use of a tube talon or bend support
| Material | Polyphenylsulfone |
|---|---|
| Temperature Rating | 210 deg F |
| Number of Outlets | 4 |
| Outlet Size | 1/2 in ProPEX |
| Type | EP Valved |
| Dimensions | 9 in L x 3.93 in H |
| Pressure Rating | 150 psi |
| Brand | Uponor |
| Fitting Type | Multi-Port Tees |
| Size | 1/2" |
| Material | Poly |
| Pex Connection Type | Expansion |
