Sioux Chief 551-P2S
*1/2 CTS PADLOCK W/SCREW
SKU
380379
Sioux Chief PadLock™ Full Clamp Tube Hanger, Series: 551-P, 1/2 in CTS Pipe/Tube, 12 lb, Polyethylene, For Use With: CTS Copper, PEX or CPVC Tubing, 160 deg F, 1 in L x 3/8 in W x 1-1/8 in H, Domestic
- Nail or screw locks tube into hanger so there is no way for tube to escape
- Will not damage tube if nail or screw is over-driven
- Allow tube to expand and contract
- Isolates tube from surface to reduce heat loss and noise transfer
- Fit and fasten to the Grid iron bracket
- UV resistant high density polyethylene body
- Zinc-plated, pan head Philips with drill tip screw
- Position clamp around tube, secure to structure using nail or screw provided
| Pipe/Tube Size | 1/2 in CTS |
|---|---|
| Domestic/Import | Domestic |
| Temperature Rating | 160 deg F |
| Suitable For Use With | CTS Copper, PEX or CPVC Tubing |
| Load Capacity | 12 lb |
| Dimensions | 1 in L x 3/8 in W x 1-1/8 in H |
| Material | Polyethylene |
| Series | 551-P |
| Brand | Sioux Chief |
| Size | 1/2" |
