American Standard T420740.002
2-HANDLE THERM VALVE TRIM KIT
SKU
729914
American Standard Thermostat Trim Kit, Round, Portsmouth® Collection, 1 Handle, Metal Lever Handle, 7-5/8 in Dia Trim, Ceramic Disc/Pressure Balanced, Hand Shower: No, Wall Mounting, For Use With: R120 Pressure Balance Valve, Brass, Satin Nickel, Import
- Without valve and volume control
- For use with R520/R540 series pressure balance valves
- Brass construction - highest quality faucet material for durability and long life
- Wax thermostatic unit - permits shuttle valve to move between the hot and cold seat to maintain the pre-selected constant water temperature
- Spring loaded check valves - when the hot and cold water enters the fitting, both supplies pass through the spring-loaded check valves to prevent cross flow of hot and cold water
- Integrated stop valves - ensure easy cleaning and servicing
- Adjustable hot limit safety stop - limits the amount of hot water allowed to mix with cold
- Reduces the risk of accidental scalding
- Back-to-back capability hot and cold can be reversed quickly and easily
- Maximum water temperature limit may be reduced to 104 or 109 deg F
| Mounting Type | Wall |
|---|---|
| Handle Type | Metal Lever |
| Finish/Color | Satin Nickel |
| Material | Brass |
| Domestic/Import | Import |
| Hand Shower Yes/No | No |
| Trim Size | 7-5/8 in Dia |
| Type | Round |
| Valve/Cartridge Type | Ceramic Disc/Pressure Balanced |
| Collection | Portsmouth® |
| Number of Handles | 1 |
| Suitable For Use With | R120 Pressure Balance Valve |
| Brand | American Standard |
