Leviton T5325
T5325 15A-125V TR DECORA BRN
SKU
702186
Leviton®, T5325, Straight Blade Receptacle, Duplex Grounding Tamper-Resistant, 125 VAC, 15 A, 2 Pole, 3 Wires, NEMA 5-15R NEMA Rating, Commercial Grade, NEMA WD-6 Enclosure, -40 to 60 deg C, Quick-Wire® Push-In/Side Wire Terminal, Thermoplastic, Brown, 4.2 in H x 1.33 in W x 0.76 in D Dimensions
- Terminal screws accept up to #12 AWG copper or copper clad wire
- Double wipe power contacts for reliable conductivity and plug retention
- Heavy gauge zinc plated steel mounting strap
| Dimensions | 4.2 in H x 1.33 in W x 0.76 in D |
|---|---|
| Amperage Rating | 15 A |
| Color | Brown |
| Grade | Commercial |
| Voltage Rating | 125 VAC |
| Number of Wires | 3 |
| Material | Thermoplastic |
| Temperature Rating | -40 to 60 deg C |
| Number of Poles | 2 |
| Type | Duplex Grounding Tamper-Resistant |
| NEMA Rating | NEMA 5-15R |
| Enclosure | NEMA WD-6 |
| Terminal Type | Quick-Wire® Push-In/Side Wire |
| Brand | Leviton Mfg |
| Color | Brown |
| Voltage | 125V |
| Type | Straight Blade |
| Amperage | 15A |
| Number | Duplex |
