Uponor A2700302

SKU
638184

Uponor TruFLOW™ Manifold Assembly, 3 Outlets, 1 in Outlet, 43.8 to 145 psi, 68 to 194 deg F, Stainless Steel, 8.9 in L x 14 in W, Import

  • The 1-1/4 in manifolds with 2 through 7 loops are strategically designed with 1 in NPT ball valves to avoid adding extra costs while maintaining the maximum flow of the manifold assembly
  • AISI304 stainless steel
  • Brass CW614N-UNI EN12164, CW617N-UNI EN12165 manifold components
  • 1 in ID manifold body
  • 1.1 Cv manifold assembly loop
  • R32 manifold body threaded connections
  • R20 manifold loop threaded connections
  • 14 gpm maximum fluid flow rate
  • The 1 in stainless-steel manifolds are fully assembled and ready for installation, manifold assembly comes with mounting brackets, isolation valves, balancing valves, fill/purge ports, air vents, ball valves, temperature gauges and end caps, Manifold adapters and fittings are sold separately
  • Accessories and Replacement Parts: A2771010: Mounting Bracket for Stainless-steel Manifold, 1 in, replacement part, set of 2, A2771021: Stainless-steel Manifold Flow Meter 1.5 GPM Valve Body, replacement part, A2771030: Stainless-steel Manifold Isolation Valve Body, replacement part, A2771035: Stainless-steel Manifold Isolation Valve Body, O-ring, replacement part, A2771040: Stainless-steel Manifold Replacement Gasket for R32 Union Connection, A2771060: Spacer Ring VA10 for White Thermal Actuator
  • Isolation and balancing, ball valves, 4 loops
More Information
Brand Uponor
Weight (lb) 10.4
Manufacture Name Uponor
Brand Name Uponor
Length (in) 20.0
Height (in) 4.17
Width (in) 15.0
Country USA
Tax Class Name taxable goods
Item Condition new condition
Product Truck Shipping Flag no
Country of Manufacture United States
Dimensions 8.9 in L x 14 in W
Domestic/Import Import
Pressure Rating 43.8 to 145
Pressure Rating UOM psi
Material Stainless Steel
Temperature Rating UOM deg F
Number of Outlets 3
Outlet Size (in) 1
Temperature Rating 68 to 194
