Uponor A2720702

Uponor TruFLOW™ Manifold Assembly, 7 Outlets, 1-1/4 in Outlet, 43.8 to 145 psi, 68 to 194 deg F, Stainless Steel, 8.9 in L x 22.31 in W, Import

• The 1-1/4 in manifolds with 2 through 7 loops are strategically designed with 1 in NPT ball valves to avoid adding extra costs while maintaining the maximum flow of the manifold assembly
• AISI304 stainless steel
• Brass CW614N-UNI EN12164, CW617N-UNI EN12165 manifold components
• 1 in ID manifold body
• 1.1 Cv manifold assembly loop
• R32 manifold body threaded connections
• R20 manifold loop threaded connections
• 14 gpm maximum fluid flow rate
• The 1 in stainless-steel manifolds are fully assembled and ready for installation, manifold assembly comes with mounting brackets, isolation valves, balancing valves, fill/purge ports, air vents, ball valves, temperature gauges and end caps, Manifold adapters and fittings are sold separately
• Accessories and Replacement Parts: A2771011: Mounting Bracket for Stainless-steel Manifold, 1-1/4 in, replacement part, set of 2, A2771021: Stainless-steel Manifold Flow Meter 1.5 GPM Valve Body, replacement part, A2771030: Stainless-steel Manifold Isolation Valve Body, replacement part, A2771035: Stainless-steel Manifold Isolation Valve Body, O-ring, replacement part, A2771040: Stainless-steel Manifold Replacement Gasket for R32 Union Connection, A2771060: Spacer Ring VA10 for White Thermal Actuator
• Isolation and balancing, ball valves, 4 loops
