Mersen USCC2
2P 30A CC FUSEHOLDER
SKU
706599
Mersen UltraSafe™ Fuse Holder, Series: USCC, 600 VAC/VDC, 30 A, 2 Pole, 2 Phase, Class: CC, Fuse Holder Code: D/W, Pressure Plate, 14 to 6 AWG Wire, DIN Rail Mount, -40 to 85 deg C, For Use With: ATDR, ATMR and ATQR Series Fuse, Polyamide, 3.07 in L x 1.38 in W x 2.32 in H
- IP20 finger safe (touch safe)
- Optional visual blown fuse indicator lights
- Compact footprint
- Quick, tool-free, easy fuse change outs
- Phillips/slot head terminal screws
- 14 to 6 AWG (single conductor), 14 to 10 AWG (dual conductor) wire size
- 200 kA short circuit current rating
| Dimensions | 3.07 in L x 1.38 in W x 2.32 in H |
|---|---|
| Wire Size | 14 to 6 AWG |
| Number of Poles | 2 |
| Amperage Rating | 30 A |
| Mounting Type | DIN Rail |
| Material | Polyamide |
| Suitable For Use With | ATDR, ATMR and ATQR Series Fuse |
| Fuse Holder Code | D/W |
| Voltage Rating | 600 VAC/VDC |
| Temperature Rating | -40 to 85 deg C |
| Number of Phases | 2 |
| Connection Type | Pressure Plate |
| Class | CC |
| Series | USCC |
| Brand | Merson Fuses |
