Siemens WMM52125RJ
5G 125A RESI METER STACK
SKU
790120
Siemens Power Mod™ Meter Stack, 6-Cutout 3/4-Wire Extra Jaw Insulated, Series: WMM, Underground Feed, 120/208 VAC, 240/120 VAC, 1200 A Bus, 125 A Socket, 5 Meter Sockets, 1/3, Ringless Socket Cover Style, 5 Socket Jaws, HQP/MP-T/MP-HT/MP-MT/QP/QPH Breaker, NEMA 3R Enclosure, Rail Mounting, 60 in H x 14 in W x 10 in D
- Exclusive knockout plate offers flexibility when pulling wires to the stack
- New breaker supports keep breakers level and straight
- Moveable neutrals and grounds to save wire
- QuickSystem™ features all designed with the contractor in mind
- 3-phases 4-wire solid neutral incoming and 1-phase 3-wire solid neutral outgoing
- Without bypass
| Feed Type | Underground |
|---|---|
| Mounting Type | Rail |
| Socket Jaws | 5 |
| Type | 6-Cutout 3/4-Wire Extra Jaw Insulated |
| Phase | 1/3 |
| Bus Amps | 1200 A |
| Enclosure Type | NEMA 3R |
| Series | WMM |
| Dimensions | 60 in H x 14 in W x 10 in D |
| Socket Amps | 125 A |
| Socket Cover Style | Ringless |
| Voltage Rating | 120/208 VAC, 240/120 VAC |
| Number of Meter Sockets | 5 |
| Breaker Type | HQP/MP-T/MP-HT/MP-MT/QP/QPH |
| Brand | Siemens Ind |
