Hubbell YA292N
250 CU 2-HOLE LONG 1/2
SKU
806030
BURNDY® HYLUG™ Compression Lug, 2-Hole, Series: YA-2N, 250 kcmil Conductor, Die Code: 16, 600 VAC to 35 kV, 1/2 in Stud, Standard Tongue, 1.11 in W x 0.16 in THK Tongue, 5.21 in Overall Length, Chamfered/Long Barrel, 1.62 in L Barrel, 1.11 in Pad, 1-3/4 in Hole Spacing, 90 deg C, Tin Plated Copper, Yellow
- Without inspection window
| Temperature Rating | 90 deg C |
|---|---|
| Color | Yellow |
| Specifications | 1.11 in Pad, 1-3/4 in Hole Spacing |
| Barrel Size | 1.62 in L |
| Conductor Size | 250 kcmil |
| Stud Size | 1/2 in |
| Voltage Rating | 600 VAC to 35 kV |
| Barrel Type | Chamfered/Long |
| Die Code | 16 |
| Overall Length | 5.21 in |
| Series | YA-2N |
| Tongue Size | 1.11 in W x 0.16 in THK |
| Tongue Type | Standard |
| Material | Tin Plated Copper |
| Type | 2-Hole |
| Brand | Burndy LLC |
