Xylem 10GS07422C
10 GPM 3/4 HP 2-WIRE SUB PUMP
SKU
740930
Goulds Submersible Pump, Standard Capacity, Series: 10GS, 10 gpm, 2 Wires, 10 Stage, 240 ft Maximum Head, 3/4 hp, 230 VAC, 60 Hz, 1 ph, 3450 rpm Motor, Noryl® Impeller, Proprietary Engineered Polymer Bearing, 304 Stainless Steel
- Field serviceable
- Sand resistant construction
- 4 in motor
- 3.9 in effective diameter with cable guard
- Rotation is counterclockwise when observed from pump discharge end
- 1-1/4 in NPT discharge
- 13.6 in water end L
- 3 to 16 gpm flow range
- Model 10GS07
| Maximum Head | 240 ft |
|---|---|
| Flow Rate | 10 gpm |
| Power Rating | 3/4 hp |
| Series | 10GS |
| Phase | 1 ph |
| Frequency Rating | 60 Hz |
| Motor Speed | 3450 rpm |
| Type | Standard Capacity |
| Impeller Type | Noryl® |
| Material | 304 Stainless Steel |
| Bearing Type | Proprietary Engineered Polymer |
| Voltage Rating | 230 VAC |
| Number of Wires | 2 |
| Number of Stages | 10 |
| Brand | Goulds |
| Pumps | Pumps |
