Bell & Gossett 117416LF
LF B&G 1IPS CIRCUIT SETTER
SKU
189920
Bell & Gossett Circuit Setter Plus® Balance Valve, 1 in Nominal, NPT End Style, 400 psig Pressure, -4 to 250 deg F, 3.81 in Inlet to Outlet Length, Brass Body, EPDM Trim, Glass/Carbon Filled TFE Seat Ring Softgoods, 2.47 in W x 3.42 in H Dimensions
- Save time, energy and water with the lead-free circuit setter plus and circuit setter plus RF
- Designed for all plumbing and HVAC systems
- Provides equal flow throughout all circuits to conserve water and optimize system efficiency
- Calibrated accurate flow control and measurement
- Bi-directional design allows any installation configuration
- Externally adjustable manual balance valve for easy adjustment
- Reduces pump energy requirements
- Meets or exceeds stringent codes for potable water
- Includes memory stop indicator
- Provides drain option
- Provides positive shut off and isolation
- Brass with EPT check valves readout valve
- 304 stainless steel ball
- Lead free
- Includes pressure/temperature ports
- Model CB-1 LF
| Pressure Rating | 400 psig |
|---|---|
| Dimensions | 2.47 in W x 3.42 in H |
| End Style | NPT |
| Trim Material | EPDM |
| Body Material | Brass |
| Temperature Rating | -4 to 250 deg F |
| Nominal Size | 1 in |
| Inlet to Outlet Length | 3.81 in |
| Softgoods Material | Glass/Carbon Filled TFE Seat Ring |
| Brand | Bell & Gossett |
