EATON 1995V
MONENTARY CENTER OFF SW
SKU
676477
EATON Arrow Hart Toggle Switch, 3-Position, 120/277 V, 20 A, 1/2 hp Power, 20 A at 120/277 VAC Contact, 1 Pole, Momentary/Toggle Actuator, Wall Mounting, Screw Terminal, Polycarbonate, Ivory, Environmental Conditions: -40 to 65 deg C Operating Temperature, 0.75 in W x 0.88 in D Dimensions
- Dual back-wire holes for feed-through wiring
- 1-piece brass contact arm and large silver alloy contact assure low resistance switching
- Spring-loaded terminal screws
- 0.05 in THK plated steel strap to withstand abuse
- Color-coded faces identify blue 15 A, red 20 A, green 30 A average
- 3.28 in L screw to screw
- 2.13 in L back
| Dimensions | 0.75 in W x 0.88 in D |
|---|---|
| Power Rating | 1/2 hp |
| Voltage Rating | 120/277 V |
| Mounting | Wall |
| Environmental Conditions | -40 to 65 deg C Operating Temperature |
| Contact Rating | 20 A at 120/277 VAC |
| Color | Ivory |
| Type | 3-Position |
| Number of Poles | 1 |
| Material | Polycarbonate |
| Terminal Type | Screw |
| Amperage Rating | 20 A |
| Actuator | Momentary/Toggle |
| Brand | Cooper Wiring Devices |
| Amperage | 20 Amp |
| Type | Toggle |
| Voltage | 120/277V |
| Color | Ivory |
