EATON S20N11S03N
3KVA 480 TO 120/240 TRANS.
SKU
824855
EATON Distribution Transformer, Type EP Dry Encapsulated, 240/480 VAC Primary, 120/240 VAC Secondary, 3 kVA Power, 60 Hz Frequency, 1 ph, Lug Connection, 176 Frame Circuit, Upright Mounting, 180 deg C Insulation, NEMA 3R Enclosure, 115 deg C, Steel Housing Material, 8 in L x 7.69 in W x 14.25 in H Dimensions
- Primary taps allow compensation for source voltage variations
- Transformer core is constructed using high grade, non-aging, silicon steel to provide high magnetic permeability
- Maximum magnetic flux densities are substantially below the saturation point, allowing for more efficient operation
- Aluminum windings
- No taps
- All insulation materials are flame-retardant and do not support combustion for added safety
- Core and coil assembly is impregnated with non-hygroscopic, thermosetting varnish and cured to reduce hot spots and seal out moisture
- Audible sound levels are lower than IEEE requirements when properly installed
| Frequency Rating | 60 Hz |
|---|---|
| Circuit Type | 176 Frame |
| Dimensions | 8 in L x 7.69 in W x 14.25 in H |
| Mounting Type | Upright |
| Connection Type | Lug |
| Enclosure Type | NEMA 3R |
| Power Rating | 3 kVA |
| Insulation | 180 deg C |
| Housing Material | Steel |
| Type | Type EP Dry Encapsulated |
| Temperature Rating | 115 deg C |
| Phase | 1 ph |
| Primary Voltage | 240/480 VAC |
| Secondary Voltage | 120/240 VAC |
| Brand | Eaton |
